Samples

Table of contents

• Importing Samples
• Universal Render Pipeline
• Running Samples
• River
• Grand Canyon
• Water Modifiers
• Volcano
• Terraform
• Simple Terraform
• Tiled Simulation
• Runtime Setup
• Scene Configuration

Important Info! To prevent project bloat the samples are not imported into your Assets folder by default. Follow the instructions below to import them.

Fluid Frenzy contains five sample scenes to showcase the functionality and help with understanding how to work with the fluid simulation. You can import the samples using the Package Manager.

Importing Samples

1. Open the Package Manager.


2. Select In Project.
3. Select Fluid Frenzy in the list under Packages - Frenzy Byte.
4. Go to the Samples tab.
5. Click the Import button.



Universal Render Pipeline

All samples withing the package are designed for the Built-in Render Pipeline but are functional with all Render Pipelines. When opening the samples with the Universal or High-Definition Render Pipeline active the sample materials are automatically upgraded when opening the sample scene.

Running Samples

To run the samples, open any of the scenes in the Assets/Samples/Fluid Frenzy/1.0.7/Samples folder and click play. Scenes can be loaded at run-time in the Scenes tab in the UI. There are several options in the UI Input Tab to select from. Control the fluid input type, fluid rigid body spawning, boat driving and “FlyCam”.

Note: The samples optionally use the Unity Post-Processing package for higher-quality visuals. It will be automatically enabled if the Post-Processing package is imported into the project.

Controls

All samples are designed to be compatible with both the Unity Input System package and the Legacy Input Manager. The system automatically checks for the presence of the new Input System package at runtime and uses it if available; otherwise, it defaults to the Legacy Input Manager. This ensures the controls below function regardless of your project’s input configuration.

• F1 - select the Fly Cam to fly around the scene using the ‘WASD’ keys and mouse.
• F2 - select the Offset Cam which follows around the Player Boat.
• F3 - select the Third Person Cam which follows around the Player Boat.
• F4 - select the Smooth Third Person Cam which follows around the Player Boat.
• F5 - select the Orbit Cam which orbits around the Player Boat and can be controlled with the mouse.
• F6 - enables the RTS Cam which can be used to pan over the scene using the ‘WASD’ keys.
• 1-9 - select the simulation input mode depending on the scene loaded. 1 Is always water.
• ‘WASD’ - controls the Fly Cam, RTS Cam, and the Player Boat, allowing you to move forward.
• Arrows - rotates the Fly Cam and RTS Cam.
• Mouse Left - when held rotates Fly Cam and RTS Cam when moving the mouse.
• Mouse Right - when held adds the selected fluid/terrain to the simulation at the mouse location.eld adds the selected fluid/terrain to the simulation at the mouse location.

River

The River sample shows the use of Fluid Modifier Volume adding water from multiple sources to create three river branches. The camera starts at the end of one of these branches with a boat that can be driven across the scene. Water flows out of the scene due to the Open Borders functionality of the fluid simulation to prevent flooding of the scene. This scene makes use of the Unity Terrain so modifying the terrain in real-time is not possible.

An alternative scene, RiverFlow, is also available and utilizes the FlowFluidSimulation instead of the default FluxFluidSimulation. The FlowFluidSimulation is an alternative fluid dynamics model that may offer different performance characteristics and simulation behavior compared to the FluxFluidSimulation.

Grand Canyon

The Grand Canyon sample shows the use of Fluid Modifier Volume adding water from multiple sources on top of the canyon filling the canyon below. The camera starts a boat that can be driven across the scene. Water stays in the scene due to the Open Borders functionality of the fluid simulation being disabled causing the scene to eventually flood. This scene makes use of the Unity Terrain so modifying the terrain in real-time is not possible.

Water Modifiers

The Water Modifiers sample shows the use of Fluid Modifier Waves to create different types of waves, Fluid Modifier Volume to create a vortex, and Fluid Rigidbody showcasing buoyancy and advection of objects. The camera starts overlooking the vortex, you can add water and spawn Fluid Rigid Bodies using the mouse.

Volcano

The Volcano scene showcases that different fluids can be rendered like lava. This scene uses the Lava Surface Fluid Renderer to create an erupting volcano. This scene makes use of the Unity Terrain so modifying the terrain in real-time is not possible.

Terraform

The Terraform scene showcases God Game simulation with two types of fluid interacting with each other and erosion of the top sand layer. Water and Lava are automatically added to the scene from different locations and when they touch they turn into rocky terrain and steam. Fluid and Terrain can be added using the mouse input as described in the controls section. This scene makes use of a custom terrain allowing modifications to be made to it in real-time by adding erodible sand, or non-erodible rock and vegetation.

An alternative scene, TerraformFlow, is also available and utilizes the FlowFluidSimulation instead of the default FluxFluidSimulation for its fluid dynamics. The FlowFluidSimulation is an alternative fluid dynamics model that may offer different performance characteristics and simulation behavior compared to the FluxFluidSimulation.

Simple Terraform

The Simple Terraform scene offers a minimal version of the full Terraform simulation, focusing on ease of use and script readability. Unlike the main samples (like Terraform), where available fluids and terrain layers are dynamically generated at runtime from a centralized Scene Configuration file, this scene utilizes a simpler setup where the UI buttons for adding materials (e.g., Water, Lava, Sand) are fixed and hardcoded within the scene’s scripts. This design is intended for users who wish to quickly copy and integrate the core terraforming logic into their own scenes without relying on the dynamic configuration system.

Note: The scripts, scene and UI components in this sample are setup with specific type of terrain layers and fluids. If you wish to reuse the scripts make sure your scene is setup the same or modify your layers accordingly.

Tiled Simulation

Demonstrates multiple simulations that neighbour each other on different Terrain tiles interacting with each other. In this sample fluid from each tile can flow into it’s neighbouring tile. Allowing the creation of larger and non-square scenes. More information can be found here

Runtime Setup

Demonstrates how to setup a fluid simulation at runtime. This can be useful for when a game makes use of procedurally generated terrain that does not exist before entering playmode.

Scene Configuration

The SceneConfiguration is a central Scriptable Object asset used across many of the provided samples (such as River, Grand Canyon, and Terraform) to define the available fluids and terrain materials for a scene.

This approach decouples the UI and simulation setup from the core scene logic. A typical SceneConfiguration asset includes lists of:

• Fluid materials (e.g., Water, Lava).
• Terrain layers (e.g., Erodible Sand, Non-Erodible Rock, Vegetation).

At runtime, sample scenes load this configuration to dynamically generate UI elements (like buttons for adding fluid or terrain materials). This system allows developers to easily modify the types of fluids and terrain available in a scene without needing to change the underlying scene code or scripts. The Simple Terraform scene is the primary exception, as it uses a fixed setup for simplicity.
